Using the Serve Module for Production Inference

This tutorial demonstrates how to use the serve function from the CulicidaeLab library for high-performance, production-ready inference. The serve function is designed to be a lightweight, fast, and safe way to run predictions.

This guide will cover:

• Speed and Safety: How the serve function uses the ONNX backend for fast inference.
• Single Image Prediction: How to use serve for classification.
• Caching: Understand the in-memory caching for predictor instances.
• Clearing the Cache: How to clear the cache when needed.

Install the culicidaelab library if not already installed

!pip install -q culicidaelab[full]

1. Initialization and Setup

We will initialize the DatasetsManager to get some sample data. The serve function doesn't require manual initialization of predictors.

Import necessary libraries

import matplotlib.pyplot as plt

# Import the required classes from the CulicidaeLab library
from culicidaelab import (
    DatasetsManager,
    get_settings,
    serve,
    clear_serve_cache,
)

# Get the default library settings instance
settings = get_settings()

# Initialize the services needed to manage and download data
manager = DatasetsManager(settings)

2. Loading the Test Dataset

We will use a built-in test dataset to get an image for our predictions.

print("--- Loading the 'classification' dataset's 'test' split ---")
classification_test_data = manager.load_dataset("classification", split="test")
print("Test dataset loaded successfully!")
print(f"Number of samples in the test dataset: {len(classification_test_data)}")

# Let's select one sample to work with.
classification_test_data = classification_test_data.shuffle(seed=42)
sample = classification_test_data[0]
image = sample["image"]
ground_truth_label = sample["label"]

print(f"\nSelected sample's ground truth label: '{ground_truth_label}'")

# Display the input image
plt.figure(figsize=(6, 6))
plt.imshow(image)
plt.title(f"Input Image\n(Ground Truth: {ground_truth_label})")
plt.axis("off")
plt.show()

Out:

--- Loading the 'classification' dataset's 'test' split ---
Cache hit for split config: test C:\Users\lenova\AppData\Local\culicidaelab\culicidaelab\datasets\mosquito_species_classification\4d967a30111bf29f
Test dataset loaded successfully!
Number of samples in the test dataset: 328

Selected sample's ground truth label: 'aedes_triseriatus'
C:/Users/lenova/CascadeProjects/culicidaelab/docs/en/examples/tutorial_part_5_serve_module.py:85: UserWarning: FigureCanvasAgg is non-interactive, and thus cannot be shown
  plt.show()

3. Using serve for Classification

The serve function automatically initializes the predictor with the ONNX backend on the first call and caches it for subsequent requests.

Run classification using the serve function

print("--- Running classification for the first time (will initialize predictor) ---")
classification_result = serve(image)

# Print the top 5 predictions
print("\n--- Top 5 Classification Predictions ---")
for p in classification_result.predictions[:5]:
    print(f"{p.species_name}: {p.confidence:.2%}")

Out:

--- Running classification for the first time (will initialize predictor) ---
Initializing 'classifier' predictor for serving...

--- Top 5 Classification Predictions ---
Aedes triseriatus: 99.81%
Aedes geniculatus: 0.19%
Culiseta longiareolata: 0.00%
Aedes canadensis: 0.00%
Culex pipiens: 0.00%

4. Caching in Action

If you run the same request again, you'll notice it's much faster because the predictor is already in memory.

Run classification again to see the caching effect

print("\n--- Running classification for the second time (should be faster) ---")
classification_result_cached = serve(image, predictor_type="classifier")

# Print the top 5 predictions again
print("\n--- Top 5 Classification Predictions (from cache) ---")
for p in classification_result_cached.predictions[:5]:
    print(f"{p.species_name}: {p.confidence:.2%}")

Out:

--- Running classification for the second time (should be faster) ---

--- Top 5 Classification Predictions (from cache) ---
Aedes triseriatus: 99.81%
Aedes geniculatus: 0.19%
Culiseta longiareolata: 0.00%
Aedes canadensis: 0.00%
Culex pipiens: 0.00%

5. Clearing the Cache

If you need to free up memory or reload the predictors, you can use the clear_serve_cache function.

Clear the cache

print("\n--- Clearing the predictor cache ---")
clear_serve_cache()

# Run classification again, it will re-initialize the predictor
print("\n--- Running classification again after clearing cache (will re-initialize) ---")
classification_result_after_clear = serve(image)

print("\n--- Top 5 Classification Predictions (after cache clear) ---")
for p in classification_result_after_clear.predictions[:5]:
    print(f"{p.species_name}: {p.confidence:.2%}")

Out:

--- Clearing the predictor cache ---

--- Running classification again after clearing cache (will re-initialize) ---
Initializing 'classifier' predictor for serving...

--- Top 5 Classification Predictions (after cache clear) ---
Aedes triseriatus: 99.81%
Aedes geniculatus: 0.19%
Culiseta longiareolata: 0.00%
Aedes canadensis: 0.00%
Culex pipiens: 0.00%

Total running time of the script: ( 0 minutes 1.507 seconds)

Download Python source code: tutorial_part_5_serve_module.py

Download Jupyter notebook: tutorial_part_5_serve_module.ipynb
